Brandenburger Thermal Insulation

The experience of our customers demonstrates that by using our plates and thermal insulator systems, a higher admissible compression charge can be obtained due to the high power insulator:

           The distribution of more uniform temperatures in the processing environment.
           And the guarantee of the additional quality for the products.
           Not only in shorter cycle times.
           And consequently the reduction of costs given the substantial saving of thermal energy.


Campos de aplicación de los aislamientos térmicos Brandenburger

  • Prensas, extrusión, forja y estampación en caliente, industria del plástico, caucho, fabricación de ruedas y neumáticos.
  • Moldes para los sectores de caucho y goma así como moldes de compresión, inyección y cámara caliente.
  • Sector madera: Prensas en continuo para tableros aglomerados (Prensas Siempelkamp, etc) y maquinaria para la madera en general.
  • Aeropespacial
  • Revestimiento térmico para hornos
  • Aislamientos de moldes y útiles para RTM. Aislamiento de Moldes y Platos para sector compresión.

Overview



The following graph shows the comparative effect of our qualities?, being the thickness of the plate in terms of comparing millimeters:

Gráfico


For more information, please contact us through post mail or by telephone. This information can be found in the contact section.


Temperature resistance
Product name Long-Term Short-term Compressive strength K-factor W/mK
< 300°C
KV 3 250 °C 280 °C 450 N/mm2 0,25 W/mk
KV 3eco 250 °C 280 °C 500 N/mm2 0,25 W/mk
BRA-GLA SI 280 °C 350 °C 200 N/mm2 0,22 W/mk
BRA-GLA 3 230 °C 250 °C 350 N/mm2 0,30 W/mk
BRA-GLA N 210 °C 230 °C 290 N/mm2 0,30 W/mk
S 4000 HT 230 °C 250 °C 200 N/mm2 0,18 W/mk
S 4000 200 °C 250 °C 100 N/mm2 0,12 W/mk
XGD 60 210 °C 250 °C 300 N/mm2 0,30 W/mK
XGD 25 200 °C 250 °C 150 N/mm2 0,18 W/mK
XGD 16 180 °C 220 °C 130 N/mm2 0,18 W/mK
XGD 80 250 °C 280 °C 500 N/mm2 0,35 W/mK
>300°C
BRA-BOARD HT 1000 °C 1100 °C 30 N/mm2 0,22 W/mk
BRA-BOARD HT 4 850 °C 935 °C 10 N/mm2 0,09 W/mk
BRA-BOARD T 500 °C 550 °C 75 N/mm2 0,30 W/mK
GL-P 500 °C 800 °C 240 N/mm2 0,31 W/mk
GL-M 400 °C 600 °C 250 N/mm2 0,30 W/mk
Exterior Insulation Materials
BRA-GLA KA 450 °C 500 °C 4 N/mm2 0,05 W/mK
BRA-FLEX 280 °C 300 °C 0,06 W/mk
BRA-GLA MP 270 °C 280 °C 5 N/mm2 0,09 W/mK
BRA-GLA HC 230 °C 250 °C 2,8 N/mm2 0,08 W/mK
XGD 15 200 °C 220 °C 80 N/mm2 0,16 W/mK
S 4000 A 230 °C 250 °C 14 N/mm2 0,09 W/mK
BRAFLEX PROTECT (Disponible en tubo y banda plastilina) 250 °C 0,09 W/mK
Side Bearing Materials
BL 70 280 °C 290 °C 2 N/mm2 0,31 W/mK
BL 40 240 °C 250 °C 120 N/mm2 0,45 W/mK
BL 30 230 °C 250 °C 110 N/mm2 0,45 W/mk
Ablation materials
S 7000 230 °C 3000 °C 0,35 W/mk
S 5000 230 °C 3000 °C 90 N/mm2 0,35 W/mk
S 2000 200 °C 3000 °C 130 N/mm2 0,25 W/mk
Compensation layers
AE 2000 N 200 °C 220 °C 150 N/mm2
Mounting tools
Mounting paste 300 °C 1400 °C
Ceramic non adhesiv mediu 300 °C 1200 °C
Impermeabilizante de aislantes térmicos Recubrimiento FP

 The table may be dowloaded as a PDF
